VM088Q

8 to 10.5GHz / 40W
GaN/SiC Power Amplifier

The VM088Q is a packaged power amplifier developed on 250nm GaN/SiC process and is internally matched through 50Ω RF accesses. It can provide an output power up to 20W and associated power added efficiency of 30% in pulsed mode.
The VM088Q is offered a plastic 48 leads 7×7 QFN designed to a surface mount design board.
The VM088Q integrates the VWA5000088AB VectraWave HPA.

POWER AMPLIFIERS > 3W

Download

Features

  • Operating frequency range: 8 to 10.5 GHz
  • Output Power : >46dBm @Pin=23dBm
  • PAE : 35% @Pin=23dBm
  • Linear Gain: 29dB
  • DC bias: VD=+28V, IDQ=350mA (VG=-2.35V Typ.)
  • Plastic QFN : 7mm x 7mm 48 leads
