The VM164F is a High Power Amplifier MMIC operating in the frequency range from 8 to 10.75GHz.
The device is developed on a 250nm GaN/SiC process and is internally matched through 50Ω RF accesses.
It provides an output power of 50W, and associated Power Added Efficiency of 38%. The VM164F is available in Flange package.
VM164F
8 to 10.75GHz - 50W
GaN/SiC
GaN/SiC
POWER AMPLIFIERS > 3W
Features
- Operating frequency range: 8 to 10.75GHz
- Output Power: 47dBm @Pin = 26dBm
- PAE: 38% @Pin = 26dBm
- Linear Gain: 29dB
- DC bias: VD = +28V, IDQ = 550mA, VG = -2.4V (Typical)
- Flange size: 11 x 17.3 (mm)
