The VWA5001175AA is a Microwave Monolithic Integrated Circuit (MMIC) designed in HEMT (High Electron Mobility Transistor) structure for operating frequency range from 33 to 36GHz.
The MMIC is developed on a 150nm GaN/SiC process and is internally matched to 50Ω RF accesses. It provides an output power of 1W, and associated Power Added Efficiency of 25%.
VM175D
33 to 36GHz - 1W GaN/SiC
Medium Power Amplifier
Medium Power Amplifier
DRIVER-AMPLIFIERS < 3W
DatasheetFeatures
- Operating frequency range: 33 to 36GHz
- Output Power: 30dBm @Pin= 9dBm
- PAE: 25% @Pin= 9dBm
- Linear Gain: 27dB
- DC bias: VD= +22V, IDQ= 110mA, VG= -1.5V (Typical)
- Chip size: 4.86 x 1.62 x 0.1mm
