8 to 12GHz - 19dB - 1.0dB NF
QFN Single Bias
Low Noise Amplifier

The VWA 0001148 AA is a low noise amplifier MMIC operating in the frequency range 8 to 12GHz. The device is packaged in a 3×3 mm 16 lead Plastic Surface Mount Package (ROHS). This compo- nent uses VWA 5001134 AA VectraWave die.
The device has a linear gain of 19 dB and a typical noise figure of 1.0 dB. Typical operating supply current is only 30 mA with a supply voltage at +3 V. It is manufactured on a PHEMT Technology and is especially suited for radar and for telecommunication applications.




  • Operating frequency range: 8 to 12GHz
  • Gain: 19dB
  • Noise figure: 1.0dB
  • Gain Flatness: +/- 0.5dB
  • Input Return Loss: -10dB typ.
  • Output Return Loss: -12dB typ.
  • Power supply: 30mA @ +3V
  • Package: QFN 3 x 3mm 16 Lead
